GA 12
Demineralization Resin
Strong Base Anion (Gel)
DOSHION GA 12 is a GEL Type -II Strong Base Anion Exchange Resin with high capacity. It is based on cross-linked polystyrene matrix. DOSHION GA 12 is specially designed to give high throughput and economical operation. The basicity of this Type – II resin is lower than that of the Type – I resin and the hydrophilicity of the Type- II resin is higher than that of the Type – I resin
DOSHION GA 12 is recommended for demineralisation, oxygen removal and nitrate removal. The resins are highly resistant to osmotic shocks and attrition losses and are adaptable for both counter-current and co-current operations.
Properties
| Matrix | Cross linked Polystyrene |
| Functional group | Quaternary Ammonium Type – II |
| Ionic Form | CI- – Chloride |
| Physical Form | Hard Moist Beads |
| Particle size (mm) | 0.30- 1.20 |
| Moisture Content % | 46 – 52 |
| Total Exchange Capacity (min) (eq/L) | 1.2 |
| Bulk Density or Shipping Weight (gms/L) | 700-720 |
| Operating pH Range | 0-14 |
| Solubility in common solvents | Insoluble |
| Volume change % (max) : CI- to OH- | 17 |
Operating Conditions
| Operating Temperature (max) | °C | 40(OH-) 70 (Cl-) |
| Minimum Bed Depth | mm | 750 |
| Regenerant Concentration | % | 4-5 (NaOH) |
| Regenerant Flow Rate | *BV/hr | 2 – 6 |
| Regenerant Contact Time | Minutes | 30 |
| Regeneration Level | Kg/m3 of Resin | 30-90 (NaOH) |
| Displacement Rinse Rate | *BV/hr | 2 – 6 |
| Displacement Rinse Volume | #BV | 1-2 |
| Fast Rinse Rate | *BV/hr | 10-40 |
| Fast Rinse volume | #BV | 4 – 10 |
| Service flow rate | *BV/hr | 10-40 |
* Bed Volume/ Hour ; # Bed Volume
